Trusscore Installation Hub
Trusscore Wall&CeilingBoard – Vertical
Trusscore Wall&CeilingBoard can be installed vertically or horizontally. Follow these guidelines if you're installing the pre-finished panels vertically.
View Vertical Installation Instructions
Trusscore SlatWall
Trusscore SlatWall panels easily snap together to create a track, section, half wall, or full wall, and seamlessly integrate with Trusscore Wall&CeilingBoard for a floor to ceiling finish.
View Installation InstructionsTrusscore Trims
Trusscore offers a range of framing, finishing, and specialty trims to help you complete any project. However, each Trusscore trim has its own unique installation instructions. Watch the Trusscore Trims Overview video to see how to install yours.
Visit Trims PageDockDeck by Trusscore
DockDeck has a Clip Strip fastening system which installs with ease, hides screws, and spaces planks uniformly.
View Installation InstructionsRibCore by Trusscore
RibCore panels can be cut to size with a standard hand or power saw and quickly fastened to walls and ceilings.
View Installation InstructionsNorLock by Trusscore
NorLock uses a tongue and groove interlocking system to easily create non-load bearing partition walls and dividers.
View Installation Instructions
Cold Weather Technical Guide
This technical installation guide outlines the special adjustments you need to make if you’re installing in temperatures below 10°C (50°F).
View GuideShower Surround Technical Guide
This guide explains how to install Trusscore Wall&CeilingBoard panels in a shower enclosure for a waterproof finish and stylish design.
View GuideExpansion Joints Technical Guide
This guide provides recommendations for installing expansion joints for Trusscore panels in spaces with continuous runs of 60+ panels.
View GuidePainting Technical Guide
This guide provides product recommendations and tips for painting Trusscore panels, plus color matching recommendations.
View GuideEpoxy Floors Technical Guide
This guide provides installation recommendations when installing Trusscore alongside epoxy flooring.
View GuideInstalling Other PVC Trims Technical Guide
This guide explains the compatibility and installation of other PVC trims with Trusscore products.
View GuideWall&CeilingBoard Backloading Guide
This guide helps determine panel deflection on ceiling joist spans with different insulation types and R-values.
View GuideRibCore Backloading Guide
This guide helps determine RibCore panel deflection on ceiling joist spans with different insulation weights.
View GuideFrequently Asked Installation Questions
Trusscore products are intended to be installed in an environment where the panels have been acclimatized to a temperature between 10° and 20°C (50° and 68°F) for at least 24 hours before installation. If you're installing Trusscore products below 10°C or 50°F, review and follow our Cold Temperature Installation Guidelines for best results.
While the recommended maximum service temperature for Trusscore products is 50°C (122°F), we don't have a minimum temperature recommendation.
Fire-resistant walls contain fire to a room and prevent it from spreading into an adjacent room for a designated time. The specific requirements for code-compliant, fire-rated wall assemblies can vary based on a building's occupancy, use, and local building codes.
Trusscore Wall&CeilingBoard does not meet the requirements for fire resistance if a fire-rated wall assembly is specified by code (for example, for a residential garage separation wall). To meet code requirements, Trusscore Wall&CeilingBoard must be installed on top of an approved a fire-rated wall or ceiling assembly. For more information, visit our Fire Rating & Performance page.
Trusscore Wall&CeilingBoard can be installed with any readily available corrosion-resistant #8/#10 gauge screws with a flat-bottomed, low profile head (i.e., truss head, pancake head, round or washer head, cabinet, and other low profile screws) and a minimum head diameter of 3/8”. We recommend different types of screws for different wall assemblies:
Wall Assembly | Screw Recommendation |
---|---|
Wood | #8 or #10 X 1-1/4” round or washer head, truss or pancake head, cabinet, or other low profile screws. #8 x 1-1/4" Round Washer Head Steel Particle Board Screw is an excellent choice. |
Concrete | 3/16” x 1-1/4” Flathead screw (Tapcon) |
Metal Studs or Steel Studs | Self-tapping #10 X 1-1/4” Truss or Pancake Head |
Stainless steel screws are only required for highly corrosive or moist environments. For more information and installation tips, download our Trusscore Wall&CeilingBoard Installation Guide.
When cutting Trusscore Wall&CeilingBoard and Trusscore SlatWall panels to size, we recommend using a saw blade designed to cut vinyl products to avoid cracking or chipping the panels. We recommend using one of the following blades:
Description | Product Number |
---|---|
Dewalt 12" - 80T Precision Trim Saw Blade | DW3232PT |
AvantiPro 12" - 80T Fine Finish Saw Blade | P128080PP |
Dewalt 6 1/2" - 90T Construction Saw Blade | DW9153 |
Makita 7 1/2" - 40T Carbide Tipped Saw Blade | A-90629 |
Makita 6 1/2" - 44T Carbide Tipped Fine Crosscutting Saw Blade | A-98360 |
Diablo 7 1/4" - 60T Carbide Tipped Ultra Finish Saw Blade | D0760 |
Alternatively, we recommend installing a standard saw blade in reverse direction. Coarse-toothed blades should be avoided. In cold weather, move your saw through the panel slowly to prevent chipping or cracking. We recommend performing a test cut, if possible, to confirm the performance of your cutting tool.
If you need to cut holes into Trusscore panels for electrical boxes, lights, taps, and more, we recommend using one of these jigsaw, oscillating saw, or hole saw blades:
Description | Product Number |
---|---|
Bosch Basic for Metal-Thin Jig Saw Blade with 17-24 TPI | T118A |
Diablo Bi-metal General Purpose Jig Saw Blade with 5/10 TPI | DJT345XF |
Dewalt HCS Clean Cut (Wood) Jig Saw Blade with 10 TPI | DW3760H |
Milwaukee 3” Diameter Hole Dozer Hole Saw Blade with Arbor | 49-56-9670 |
Milwaukee Universal Fit Oscillating saw Blade | 48-90-1231 |
When creating a square cut-out, we recommend taking the following steps:
- Measure the location of the opening on the wall.
- Mark the perimeter of your opening on the panel.
- Drill a ½” hole in the corner of the required opening.
- Insert the blade into the hole and proceed to cut out along your marked lines. If you’re making this cut after the panel has been installed, ensure the space behind the area to be cut is free of obstructions, electrical wires, plumbing, and any other object.
For more information and installation tips for Trusscore products, download the product's installation guide on our Installation Help page.
Trusscore Wall&CeilingBoard panels have a smooth, clean finish that is scratch, dent, and damage resistant, which means they should never require painting like traditional drywall. However, we understand that sometimes people want a change and will decide to paint their panels to update or refresh their room’s look.
We recommend using 100% acrylic latex paint or acrylic latex paint with urethane additive to paint Trusscore panels. We also recommend using self-priming paints or primer and paint combination products where possible. For more information and product recommendations, download our Painting Guidelines document.
If you're installing Trusscore Wall&CeilingBoard or Trusscore SlatWall panels in combination with painted drywall, you may want to color match to create a unified design. Our top recommendations from BeautiTone, Behr, Benjamin Moore, and Sherwin-Williams for matching white and gray Trusscore panels on adjacent walls are also included in the document above.
To organize your space and attach items to your wall, we recommend installing Trusscore SlatWall. Trusscore SlatWall is a high-strength, on-the-wall storage solution that seamlessly integrates with Trusscore Wall&CeilingBoard panels and can be instantly accessorized with snap-in hooks, baskets, and shelves.
However, we understand Trusscore SlatWall may not meet your specific design needs. If you still want to mount or fasten items directly to Trusscore Wall&CeilingBoard, keep this advice in mind:
- When hanging an item directly on a Trusscore Wall&CeilingBoard panel, items should never be directly fastened without back support.
- Lightweight items (i.e., less than 30 pounds) can be attached directly to Trusscore Wall&CeilingBoard using adhesive hooks such as Command™ Hooks or using spring toggle bolt kits.
- Moderate weight items should be fastened directly to the supporting structure of the wall or ceiling through Trusscore Wall&CeilingBoard. Mounting holes should be slightly oversized to accommodate for expansion and contraction of the panel.
- Heavyweight items should be mounted directly to the supporting structure to avoid crushing your Trusscore Wall&CeilingBoard panels. We recommend cutting away the Trusscore material at the mounting points and then using metal spacers (i.e., stack of washers or nuts) to keep heavy items flush to the Trusscore panels but not crush them.
For more information and installation tips, download our Trusscore Wall&CeilingBoard Installation Guide.
